A crevasse is a deep crack, or fracture, found in an ice sheet or glacier, as opposed to a crevice that forms in rock. Crevasses form as a result of the movement and resulting stress associated with the shear stress generated when two semi-rigid pieces above a plastic substrate have different rates of movement. The resulting intensity of the shear stress causes a breakage along the faces.
Crevasses often have vertical or near-vertical walls, which can then melt and create seracs, arches, and other ice formations. These walls sometimes expose layers that represent the glacier's stratigraphy. Crevasse size often depends upon the amount of liquid water present in the glacier. A crevasse may be as deep as 45 metres, as wide as 20 metres, and up to several hundred metres long.
A crevasse may be covered, but not necessarily filled, by a snow bridge made of the previous years' accumulation and snow drifts. The result is that crevasses are rendered invisible, and thus potentially lethal to anyone attempting to navigate their way across a glacier. Occasionally a snow bridge over an old crevasse may begin to sag, providing some landscape relief, but this cannot be relied upon. Anyone planning to travel on a glacier should be trained in crevasse rescue.
The presence of water in a crevasse can significantly increase its penetration. Water-filled crevasses may reach the bottom of glaciers or ice sheets and provide a direct hydrologic connection between the surface, where significant summer melting occurs, and the bed of the glacier, where additional water may moisten and lubricate the bed and accelerate ice flow.
Types of crevasses
- Longitudinal crevasses form parallel to flow where the glacier width is expanding. They develop in areas of tensile stress, such as where a valley widens or bends. They are typically concave down and form an angle greater than 45° with the margin.
- Splashing crevasses result from shear stress from the margin of the glacier and longitudinal compressing stress from lateral extension. They extend from the glacier's margin and are concave up with respect to glacier flow, making an angle less than 45° with the margin. At the centre line of the glacier, there is zero pure shear from the margins, so this area is typically crevasse-free.
- Transverse crevasses are the most common crevasse type. They form in a zone of longitudinal extension where the principal stresses are parallel to the direction of glacier flow, creating extensional tensile stress. These crevasses stretch across the glacier transverse to the flow direction, or cross-glacier. They generally form where a valley becomes steeper.
|Crevasses around the world|
- Paterson, W.S.B., 1994, The Physics of Glaciers, 3rd edition, ISBN 0-7506-4742-6.
- Boon, S., M.J. Sharp, 2003, The role of hydrologically-driven ice fracture in drainage system evolution on an Arctic glacier, Geophysical Research Letters, 30, pp. 1916.
- van der Veen, C.J., 1998, Fracture mechanics approach to penetration of surface crevasses on glaciers, Cold Regions Science and Technology, 27, pp. 31–47.
- Zwally, H.J., W. Abdalati, T. Herring, K. Larson, J. Saba, K. Steffen, 2002, Surface melt-induced acceleration of Greenland ice-sheet flow, Science, 297, pp. 218–222.
- Mountaineering: The Freedom of the Hills, 5th edition. ISBN 0-89886-309-0.
- "Crevasse." Encyclopædia Britannica. 2010. Encyclopædia Britannica Online. 17 Oct. 2010.
- Das, S. B., I. Joughin, M.D. Behn, I.M. Howat, M.A. King, D. Lizarralde, M.P. Bhatia, 2008, Fracture propagation to the base of the Greenland Ice Sheet during supraglacial lake drainage, Science, 320, pp. 778.
- Colgan, W., H. Rajaram, W. Abdalati, C. McCutchan, R. Mottram, M. S. Moussavi, and S. Grigsby (2016), Glacier crevasses: Observations, models, and mass balance implications, Rev. Geophys., 54, doi: 10.1002/2015RG000504
